.jpg)
Brand Name:
Model Number: hc9600fkp13h
Nominal filtration rating:
Application:
Operating pressure:
Working temperature:
Replacement or not:Replacement
8PP-42057-00 Replacement for Donaldson Cartridge
Air filter cartridges
Dust collector cartridges
Air filter element
Features
The imported material woven polyester extends cartridge life
and ensures higher efficiency by filtering small particles on the
surface of the media.
Wide pleat spacing provides thorough pulse cleaning of fibrous
and agglomerative particles.
Start-up efficiency of 99.9% on 0.2~2μdust particles reflects highest
industry standard.
Flame retardant media available.
Stainless steel construction available.
MEDIA COMPATIBILITY DATA
|
Temperature Resistance
|
Moisture Absorption |
Chemical Tolerance |
Abration Resistance |
|
180F / 82???/font>
|
Maximum 14%
@70F/ 21???nbsp;and 65%RH
|
Acids—Good???/font>Oxidants—Fair
Bases—Good???/font>Solvents—Good |
Good per TAPPI 476
(Taber method???/font> |
APPLICATIONS
Excellent on applications with a combination of fibrous and non-fibrous dust including ceramics dust???/font>cotton???/font>fiber-glass???/font>grains and many more.
Proven solution for agglomerative dust.
CONFIGURATIONS
|
Collector Model |
Filter Area |
Pleated Height |
Dimentipons |
Material |
|||
|
ft2 |
m2 |
in |
mm |
in |
mm |
||
|
8PP-22269-00
|
90 |
8.4 |
2.0 |
50.8 |
13.84×26 |
351.5×660.4 |
woven polyester Stainless steel |
