Air filter Pocket G4 F5 F7 F8,Air Conditioning Bag Filter,fi

Air filter Pocket G4 F5 F7 F8,Air Conditioning Bag Filter,fi

Read 0 Reviews23 Q&As Write a Review
Pocket filters are filters used in HVAC applications to remove dust from ambient air. They are commonly used as final filters in commercial applications or as prefilters for HEPA filters in hospitals in the Pharmaceutical Industry. The filt

PARAMETER

Brand Name:
Model Number:
Nominal filtration rating:
Application:
Operating pressure:
Working temperature:
Replacement or not:Replacement

Pocket filters are filters used in HVAC applications to remove dust from ambient air. They are commonly used as final filters in commercial applications or as prefilters for HEPA filters in hospitals in the Pharmaceutical Industry. The filter is made with pieces of media, sealed together to form pockets. Each bag air filter can have a specified number of pockets, whether they be 3 pocket bag filter, or 6 pocket bag filter, the pockets themselves can vary in length. With these combinations of pockets and lengths, many surface areas sizes can be created. Generally, a larger surface area will give you better Dust Holding Capacity (DHC) and longer service life of the filter.

Material And Operation Conditions

Media

Synthetic fiber / Glass fiber

Pocket type

Sewing bag, Ultrasonic bag

Frame

Aluminum / Galvanized / Stainless steel / Plastic, in 19#, 21#, 25#, customized

Optional thickness

21 / 25mm

Efficiency

F5 / F6 / F7 / F8

Maximum Temperature

80°C

Maximum Humidity

100%

Main Features

1) Adopt superfine synthetic fiber and glass fiber; large dust holding capacity; stable efficiency in the life of using

2) Selection of optimized V-shaped bag structure; small resistance; long lifespan

3) Performance of flame-retardant is well to achieve UL-2 standard

4) Adopt U.S.A JM micro glass fiber media to make sure efficiency of filtration system.
