oil filter cartridge made in China

oil filter cartridge made in China

Read 0 Reviews23 Q&As Write a Review
Filter Element 1.HV fiberglass material 2.High efficiency and good quality

PARAMETER

Brand Name:
Model Number:
Nominal filtration rating:
Application:
Operating pressure:
Working temperature:
Replacement or not:Replacement

The Filter Element Parameters:

1.Filter accuracy: 1- 100um
2.Size:
81*41.4*41.4mm
3.Pressure: 21.0Mpa
4.Material: HV fiberglass or domestic fiberglass
5.Application field: hydraulic system, lubrication system

 Filter Element Features:

1.Function: Oil filtration
2.Working time:8-12 months
3.Efficiency:99.98%
4.Filtration medium:General hydraulic oil

5.Application field: hydraulic system, lubrication system

Quality Assurance:

ISO 2941------Collapse & Burst Resistant
ISO 2942------Fabrication & Integrity Test
ISO 2943------Material Compatibility with Fluids
ISO 3724------Flow Fatigue Characteristics
ISO 3968------Pressure Drop vs. Flow Rate
ISO 16889------Multi-pass Performance Testing

Products Test:




Products application:

1.Metallurgy: used in hydraulic system of rolling mill, caster filter and various kinds of lubrication of filtering.

2.Petrochemicals: oil refining, chemical production process of products and the separation of intermediate
products and
recovery, the oil field note well water and natural gas particle filter except.

3.Textile: polyester melt in the purification and drawing process even filter, air compressor protection filtering,
compressed
gas oil removal in addition to water.

4.Electronic and pharmaceutical: reverse osmosis water, deionized water to treatment filter and wash the liquid
and glucose
 former treatment filter.
