Suction oil Filter housing
Suction oil Filter housing
Brief introduction:
TF Tank Mounted Suction Filter Series is installed at the entrance of the oil pump,which protects the oil pump and other hydraulic components from absorbing admixture,preventing the hydraulic pollution effectively and improving the hydraulic system clear.
Technical Parameter
Media: Hydraulic oil,phosphateester hydraulic Oil ,emulsified liquid,water-glycol
Flow rate:25-1300L/min
Precision:80-180μm
Pressure:0.6MPa
Connecting:Screw, Flange
Lectotype illustration
The model of filter is TF•BH-160*80,element is TFX•BH-160*80 if the flow rate is 160L/min,the precision is 80μm.
