SGF-H30x10C duplex high pressure line filter
INTRODUCTION
The SGF series filter is composed of two single bowl filters,check valve,directional valve and indicator.It should be installed at outlet of the high-pressure line.The feature of this filter allows continuous operation even during replacing element,which is clogged by contaminant.When the pressure of the contaminant clogged element should be changed.At this time,turn the directional valve,let the other filter work,and changed the clogged element.If the element can't be changed in time until the pressure reaches to 0.6MPa,the by-pass valve will open automatically to keep the system safety.
TECHNICAL DATA
|
Model |
Flow
(L/min) |
Filtr
(um) |
Press
(Mpa) |
Dia
(mm) |
Pressure loss(Mpa) |
Indicator |
Weight
(KG) |
Connect |
Model of element |
|
Initial |
Max |
V |
A |
|
SGF-H30X* |
30 |
3
5
10
20 |
32 |
20 |
≤0.08 |
0.5 |
12
24
36
220 |
2.5
2
1.5
0.25 |
|
Flange |
PLFX-30X* |
|
SGF-H60X* |
60 |
20 |
|
DF0060D*BN3HC |
|
SGF-H110X* |
110 |
20 |
|
DF0110D*BN3HC |
|
SGF-H160X* |
160 |
32 |
|
DF0160D*BN3HC |
|
SGF-H240X* |
240 |
32 |
|
DF0250D*BN3HC |
|
SGF-H330X* |
330 |
50 |
|
DF0330D*BN3HC |
|
SGF-H500X* |
500 |
50 |
|
DF0500D*BN3HC |
|
SGF-H660X* |
660 |
50 |
|
DF0663D*BN3HC |
Note:* is filtration accuracy.If the medium is water-glycol ,usage pressure 32 MPA,flow rate 160L/min,filtration accuracy 10 um and the filter equipped with indicator.The model of filter IS SFG.BH-H160X10-C,the model of the element is DF0160D*BH3HC.
