Brand Name: LEFILTER
Model Number:
Nominal filtration rating:
Application:
Operating pressure:
Working temperature: 10-80℃
Replacement or not:Replacement
It is designed for a variety of container which can hold 1 to 37 filter elements. It can meet a variety of flow rate demands and the hardware of which has a price competitive advantage. The large diameter of filter design increases the filtration area and can greatly reduce the amount of filter elements and the shell size.
3M Equivalent filter cartridge HF60PP005D01 Application fields:
1) RO cartridge filtration and seawater desalination pretreatment
2) Filtration of condensed water in power plants
3) Filtration of bulk drug, solvent and water in bio-pharmacy industry
4) Filtration of bottled water, liquid glucose, edible oil, juice, soft drink and milk
5) Painting, petrochemical industry
6) Micro-electronics, film, fiber, resin
3M Equivalent filter cartridge HF60PP005D01 Product features:
1) High pollution assimilative capacity can prolong the service life and reduce the cost.
2) Reduce the amount of replacement filter elements and decrease labor cost.
3) The design of seal interface can reduce the risk of bypass flows and increase the filtration efficiency.
4) Easier installment and lower labor cost.
5) Wide chemical applicability can be applied to a variety of fields.
3M Equivalent filter cartridge HF60PP005D01 Technical specifications:
1) Parts materials:
Filter material: pleated fiberglass, pleated deep polypropylene (PP)
Supporting/diversion layer: polypropylene (PP)
End caps: reinforced polypropylene with fiberglass
Sealing material: EPR, PTFE fluororubber
2) Performance of filter element:
Filtering accuracy: 1micron, 3micron, 5micron, 10micron, 20micron, 50micron, 70micron
Highest operating temperature: 80℃
Maximum pressure drop: 3.4bar, 20℃
Recommended pressure drop for filter replacement: 2.4bar, 20℃
The maximum water-carrying capacity: 1300L/min
Construction | |
Filter Media | Fibergalss , Polypropylene |
Center Core | Polypropylene |
End Caps | Polypropylene reinforced with Glass fiber |
Sealing O-ring | Ethylene propylene rubber (EPR), Rubber Coated PTFE |
Performance | |
Filtration Accuracy | 1, 3, 5, 10, 20, 50, 70 μm |
Highest Operation Temperature | 80℃ |
Maximum Pressure Drop | Pleated Fiberglass-3.4Bar@20℃ |
Recommended Change-out Differential Pressure | 2.4Bar@20℃ |
Recommended Maximum Filtration Volume | 1300L/min. |
Industries | Applications |
Municipal Water General Industrial Oil & Gas Chemicals & Petrochemicals Food & Beverage Electronics | • Pre-RO Water |
• Process Waters | |
• Wastewater & Reclaimed Waters | |
• Injection & Produced Waters | |
• DE Trap | |
• Clarification | |
• Amine Sweetening | |
• Catalyst Protection/Recovery | |
• Machine Coolants |
Reduced cartridge handling & disposal
Reduced filter change-out time
Less individual cartridge seal points, reducing chance of fluid bypass
High filter loading capacity
Reproducible filter effluent quality throughout life of filter
Broad chemical compatibility
No special tools or hardware required for filter change-out
"Twist-to-lock" cartridge seating mechanism provides positive seal
Ergonomic designed handle facilitates cartridge installation and removal
HF60PP001D01, HF60PP002A01, HF60PP002B01, HF60PP002C01, HF60PP002D01, HF60PP005A01,
HF60PP005B01, HF60PP005C01, HF60PP005D01, HF60PP010A01, HF60PP010B01, HF60PP010C01,
HF60PP010D01, HF60PP015A01, HF60PP015B01, HF60PP015C01, HF60PP015D01, HF60PP025A01,
HF60PP025B01, HF60PP025C01, HF60PP025D01, HF60PP040A01, HF60PP040B01, HF60PP040C01,
HF60PP040D01, HF60PP070A01, HF60PP070B01, HF60PP070C01, HF60PP070D01,
HF40PP001A01, HF40PP001B01, HF40PP001C01, HF40PP001D01, HF40PP002A01, HF40PP002B01, HF40PP002C01,
HF40PP002D01, HF40PP005A01, HF40PP005B01, HF40PP005C01, HF40PP005D01, HF40PP010A01, HF40PP010B01,
HF40PP010C01, HF40PP010D01, HF40PP015A01, HF40PP015B01, HF40PP015C01, HF40PP015D01, HF40PP025A01,
HF40PP025B01, HF40PP025C01, HF40PP025D01, HF40PP040A01, HF40PP040B01, HF40PP040C01, HF40PP040D01,
HF40PP070A01, HF40PP070B01, HF40PP070C01, HF40PP070D01, HF60PP001A01, HF60PP001B01, HF60PP001C01,
HF60PP001D01, HF60PP002A01, HF60PP002B01, HF60PP002C01, HF60PP002D01, HF60PP005A01, HF60PP005B01,
HF60PP005C01, HF60PP005D01, HF60PP010A01, HF60PP010B01, HF60PP010C01, HF60PP010D01, HF60PP015A01,
HF60PP015B01, HF60PP015C01, HF60PP015D01, HF60PP025A01, HF60PP025B01, HF60PP025C01, HF60PP025D01,
HF60PP040A01, HF60PP040B01, HF60PP040C01, HF60PP040D01, HF60PP070A01, HF60PP070B01, HF60PP070C01
70-0201-5556-3,
70-0201-5558-9, 70-0201-5560-5, 70-0201-5562-1, 70-0201-5564-7, 70-0201-5566-2, 70-0201-5568-8,
70-0201-5570-4, 70-0201-5572-0, 70-0201-5574-6, 70-0201-5576-1, 70-0201-5578-7, 70-0201-5580-3,
70-0201-5582-9, 70-0201-5584-5, 70-0201-5586-0, 70-0201-5588-6, 70-0201-5590-2, 70-0201-5592-8,
70-0201-5594-4, 70-0201-5596-9, 70-0201-5598-5, 70-0201-5600-9, 70-0201-5602-5, 70-0201-5604-1,
70-0201-5606-6, 70-0201-5608-2, 70-0201-5610-8, 70-0201-5612-4, 70-0201-5614-0, 70-0201-5616-5,
70-0201-5618-1, 70-0201-5620-7, 70-0201-5622-3,70-0201-5624-9, 70-0201-5626-4, 70-0201-5628-0,
70-0201-5630-6, 70-0201-5632-2, 70-0201-5634-8, 70-0201-5636-3, 70-0201-5638-9, 70-0201-5640-5,
70-0201-5642-1, 70-0201-5644-7, 70-0201-5646-2, 70-0201-5648-8, 70-0201-5650-4, 70-0201-5652-0,
70-0201-5654-6, 70-0201-5657-9, 70-0201-5659-5, 70-0201-5661-1, 70-0201-5663-7, 70-0201-5665-2,
70-0201-5667-8, 70-0201-5669-4, 70-0201-5671-0, 70-0201-5673-6, 70-0201-5675-1, 70-0201-5679-3,
70-0201-5681-9, 70-0201-5700-7, 70-0702-5677-4
