Introduction of zander filter:
Zander filter element isused to filter different dismissal of stainless dry stock,
corrosion resistance, superior structural performance; seam welded for extra
strength, low resistanceto flow. Different accuracy levels of different filter structure,
a new "matrix blended fiber" media, larger effective surface area, improves capure
rate, enhanced filtering effect. Coated closed cell foam sleeve with resists chemical
attack from oils and acids, ensures high efficiencies by preventing re-entrainment
of coalesced liquids.
Advantages:
1.Duarbility and longevity
2.Beautiful design
3.High quality with reasonable price
4.Afford good service
5.Produce according to your sample or drawing
6.Each product individually tested
Features:
1.Type:Precision Filter, Filter
2.Filter material: imported fiberglass, filter felt
3.Filter accuracy:1um
4.Application: air compressor
5.Weight:1-2kgs
6.service time:8~12 months
7.sealing material:NBR, VITON
8.Oil content:0.5ppm
9.Flow rate:16Nm³/min
Technical data:
|
Flow Rate NM3/min |
Model |
|
0.5 |
1030 |
|
0.85 |
1050 |
|
1.2 |
1070 |
|
1.7 |
1140 |
|
3 |
2010 |
|
5 |
2020 |
|
7.8 |
2030 |
|
11.7 |
2050 |
|
16 |
3050 |
|
24 |
3075 |
|
Filter Precision (μm)
|
Residual Oil Component (ppm)
|
|
V Class:3
|
5
|
|
Z Class:1
|
0.5
|
|
Y Class:0.1
|
0.1
|
|
X Class:0.01
|
0.01
|
|
A Class:Active Carbon
|
0.003
|
Zander models
5075XP Zander air filter element
Zander air filter element 3050A
Zander compressed air filter 2020V
0.01 micron 2020X zander precision filter made in china
Quality assurance:
ISO 2941------Collapse & Burst Resistant
ISO 2942------Fabrication & Integrity Test
ISO 2943------Material Compatibility with Fluids
ISO 3724------Flow Fatigue Characteristics
ISO 3968------Pressure Drop vs. Flow Rate
ISO 16889------Multi-pass Performance Testing
